- Displaying high resolution pictures and rapid image processing by the SOC chip
- Auto sequence mode
- Motion detection function (when it detects any motion, it design to auto sequence mode
and ring the alarm
- Pattern change detection function
- Supporting NTSC & PAL system
- Displaying the date and time, the name of the channel and the current status
- RS-232C / RS-485 communication port for external devices
- Various mode of screen split
MODEL | SV-04HDS | SV-06HDS | |
Video Input | BNC-F(75Ω 1Vp-p) x 4 | BNC-F(75Ω 1Vp-p) x 6 | |
Video Output | BNC-F (Looped through | BNC-F (Looped through | |
HDMI x 1, D-Sub x 1, BNC x 2 | |||
Video | HDMI | Full HD:1920x1080p@50/60Hz | |
HD:1920x1080i@50/60Hz | |||
WSXGA:1680x1050@50/60Hz | |||
SXGA:1280x1024@50/60Hz | |||
D-SUB | SXGA, WSXGA | ||
BNC-F | (Monitor)720x480@50/60Hz | ||
Video Format | NTSC/PAL Selectable | ||
Split Mode | 1,2V,2H,4,4B,4R | 1,2V,2H,4,4B,4R,6 | |
OSD | Up to 9 Characters | ||
External | RJ-45 | Firmware Upgrade | |
RS-232C | External device connection | ||
T. Block | Alarm Input:4(8P) | Alarm Input:6(12P) | |
Power | 2P Terminal Block DC12V/0.5A | AC 100~240V, 50/60Hz | |
Power Consumption | 6W | 7W | |
Temperature/Humidity | 0°C~+50°C / 0~80% | ||
Casebody/Weight | Steel / 2Kg | Steel / 3.5Kg | |
Dimension(mm) | 220(W)x44(H)x190(D) | 430(W)x44(H)x350(D) |
